Tycroc shower trays are an essential component of the complete Tycroc waterproofing system. By using Tycroc shower trays and slope boards, there is no need to create floor slopes separately. Compared to traditional concrete screed solutions, the Tycroc system saves space and offers a clear advantage in terms of weight. Underfloor heating cables can be installed directly on top of Tycroc products.
Tycroc shower trays are specifically designed for constructing shower areas and shower enclosures. They can also be used in other wet environments, such as steam saunas. The subfloor does not require separate slope formation, as the Tycroc shower tray already includes the required slope. The tray can be installed on any stable and load-bearing floor structure
| PRODUCTS | DIMENSIONS |
|---|---|
| STC90 | 900 × 900 × 30 mm |
| STC100 | 1000 × 1000 × 30 mm |
| STO150 | 1500 × 1000 × 30 mm |
*produced with a thickness of 20 mm until the end of 2025
(*Manufactured with a thickness of 20 mm until the end of 2025)
| PRODUCTS | DIMENSIONS |
|---|---|
| STL90 | 900 × 900 × 30 mm |
| STL100 | 1000 × 1000 × 30 mm |
| STL150 | 1500 × 1000 × 30 mm |
| PRODUCT | DIMENSIONS |
|---|---|
| ST100 | 1000 × 1000 × 30 mm |
(*Manufactured with a thickness of 20 mm until the end of 2025)
Tycroc shower trays without a drain allow the use of a pre-ferred drain solution, which can be installed in the centre ofthe shower tray
| PRODUCTS | DIMENSIONS |
|---|---|
| SSB1530 | 1500 × 1000 × 15/30 mm |
| SSB3045 | 1500 × 1000 × 30/45 mm |
Tycroc single slope boards can be used to extend the floor slope outside the shower area or to create a custom shower tray with a preferred linear drain. They are also suitable for balcony floors, ensuring waterproofness and providing the required slope for water drainage.
The Tycroc waterproofing system is a complete solution for waterproofi ng walls, floors and ceilings using Tycroc waterproof building boards.
The system includes covering surfaces with Tycroc TWP waterproof building boards and sealing joints, washers and corners using Tycroc Premium Fix adhesive sealant.
The surface of Tycroc waterproof building boards is hydrophobic and immediately ready for tiling or other fi nishing materials.
As an alternative solution, joints and corners may also be sealed using waterproofing tape and membrane systems.
Tycroc TWP building board
Waterproofi ng tape and membrane
Wall or fl oor tile
Tile adhesive
Tycroc fi xing screw + Tycroc metal washer
Load-bearing substrate (OSB / plywood)
Structural beam
Tycroc shower tray
Tycroc linear drain
Tycroc Premium Fix adhesive sealant
